| 尺寸 | 产品型号 | 内板型号 | 金属内板规格 | |||||
| WHD | 盖：灰色ABS 盒体：灰色ABS |
盖：透明PC 盒体：灰色ABS |
盖：灰色PC 盒体：灰色PC |
盖：透明PC 盒体：灰色PC |
塑料 | 金属 | M1 | M2 |
| 300×380×183 | TB-AG-3038-1 | TB-AT-3038-1 | TB-PG-3038-1 | TB-PT-3038-1 | TJ-3038 | 293 | 373 | |
| 300×380×120 | TB-AG-3038 | TB-AT-3038 | TB-PG-3038 | TB-PT-3038 | TJ-3038 | 293 | 373 | |
| 220×300×160 | TB-AG-2230-1 | TB-AT-2230-1 | TB-PG-2230-1 | TB-PT-2230-1 | TJ-2230 | 210 | 290 | |
| 220×300×120 | TB-AG-2230 | TB-AT-2230 | TB-PG-2230 | TB-PT-2230 | TJ-2230 | 210 | 290 | |
| 190×240×160 | TB-AG-1924-1 | TB-AT-1924-1 | TB-PG-1924-1 | TB-PT-1924-1 | TJ-1924-1 | 178 | 232 | |
| 190×240×90 | TB-AG-1924 | TB-AT-1924 | TB-PG-1924 | TB-PT-1924 | TJ-1924 | 178 | 232 | |
| 140×190×70 | TB-AG-1419 | TB-AT-1419 | TB-PG-1419 | TB-PT-1419 | TJ-1419 | 126 | 176 | |
| 110×150×70 | TB-AG-1115 | TB-AT-1115 | TB-PG-1115 | TB-PT-1115 | TJ-1115 | 106 | 146 | |
| 100×100×50 | TB-AG-1010 | TB-AT-1010 | TB-PG-1010 | TB-PT-1010 | TJ-1010 | 98 | 98 | |
| 80×120×50 | TB-AG-0812 | TB-AI-0812 | TB-PG-0812 | TB-PT-0812 | TJ-0812 | 73 | 113 | |
| W/H/D | W | H | D | W3 | H3 | D1 | D2 |
| 80x120x50 | 83 | 124 | 50 | 88 | 88 | 40 | 14 |
| 100x100x50 | 104 | 104 | 50 | 68 | 108 | 40 | 14 |
| 110x150x70 | 113 | 153 | 70 | 98 | 137 | 49 | 25 |
| 140x190x70 | 140 | 194 | 70 | 128 | 177 | 51 | 25 |
| 190x240x90 | 195 | 250 | 90 | 170 | 226 | 70 | 25 |
| 190x240x160 | 195 | 250 | 160 | 170 | 226 | 70 | 96 |
| 220x300x120 | 230 | 310 | 120 | 200 | 280 | 76 | 50 |
| 220x300x160 | 20 | 300 | 160 | 200 | 280 | 76 | 90 |
| 300x380x120 | 310 | 390 | 120 | 281 | 278 | 78 | 50 |
| 300x380x183 | 310 | 390 | 160 | 281 | 278 | 78 | 110 |
